The chambers with transport system represent the most modern solution for efficient and hygienically safe heat treatment and subsequent cooling of meat products.
This system combines two chambers - the smoking or cooking chamber and the cooling chamber - into one compact unit, which brings a number of major advantages over separate chambers.
Safe and smooth operation Thanks to the automatic reloading of the carts using a stepper manipulator with hydraulic cylinders, manual handling and time loss is minimised. Once the heat treatment is complete in the first section, the system automatically moves the carts to the second section for controlled cooling. Depending on the specific configuration, guillotine or bi-fold doors are installed between the two sections to ensure a safe and hygienic separation of spaces while maintaining a smooth flow of traffic.
Automation for maximum productivity The transport system is the ideal choice for efficient and modern production of meat products where the emphasis is on automation, time saving and hygiene. Thanks to the wide range of configurations, the system can be adapted to the individual needs of each production plant.
Key Benefits Space Saving - The transport system combines two chambers into one unit, reducing space requirements in the production facility. Faster process - Instant reloading minimizes delays between production phases. Cooling begins immediately after the heat treatment is complete, which shortens the overall production cycle. Automated cart transport - The stepper manipulator with hydraulic cylinders reliably stacks and smoothly moves carts between chambers without the need for manual intervention. Reduced physical demands - Eliminating manual handling of heavy carts helps reduce worker strain and increases production ergonomics. Hygienic separation of production phases - Process separation between the raw meat and finished product sections eliminates the risk of cross-contamination and meets the highest hygiene standards.
Customized configuration: Choices as for UKM, VKM and ZKM Double leaf or guillotine doors Possibility to modify the manipulator for atypical carts
